ST925 In-Line DynaProbe pH Sensor for dairy and brewing applications

1 — Liquid Junction

• [T] Coaxial Teflon
• [R] Recessed Coaxial Teflon

2-3 — Measurement Electrode

• [33] pH, HT-3 Rugged Dome Bulb
• [43] pH, HT-4 High pH bulb (for pH 13 and above)
• [17] pH general purpose, flat bulb
• [PB] ORP, Platinum Band

4 — Temperature Compensator: (for direct input into following manufacturer’s preamp/instrument)

• [0] T.C. not required
• [1] 3K Ohms for most older Models of TBI/Bailey, Uniloc, and other US manufacturers
• [D] Pt 100 Ohms for Beckman Model SoluComp, TBI/Bailey (ABB) TB82 & TB84, Uniloc 1054, Foxboro 870 & 874, Yokogawa, and most European Models
• [H] Pt 1000 Ohms for Yokogawa, Conducta, Polymetron, LTH, & many European models

5 — Cable Type:

• [N] Jacketed Low Noise Coax w/leads – for Solution Ground and T.C.

6-7 — Cable Length:

• [07] 7 ft. is standard length
• [XX] Specify length (in feet) above 7 ft. standard length

8-9 — Required Sensor Connectors:

• [FB] BNC for pH and ferrules on all other leads (for use with Terminal Block or Terminal Strip)
• [FF] All Ferrule connectors ( for use with Terminal block or Terminal Strip)
