The SingleSenseĀ® Model SU500 Single-Use Flow-Through Conductivity Sensor is gamma irradiation compatible and designed for applications where conductivity must be continuously measured in media flowing through flexible tubing. Ideally suited for inclusion in single-use tubing sets that will be gamma sterilized and used for chromatography, TFF, or other downstream processes.
Sensor Specifications
| Type | Conductivity |
|
Measurement Principle |
4-electrode sensor |
|
Output Signal |
Analog |
|
Measurement Range |
0.1 – 100 mS/cm |
|
System Accuracy |
0.1 – 1 mS/cm +/- 0.05 mS/cm 1 – 100 mS/cm +/- 5% |
|
Operating temperature |
4Ā°C – 50Ā°C [39Ā°F – 122Ā°F] |
|
Temperature Accuracy |
+/- 0.1 Ā°C |
|
Shelf Life |
30 months |
|
Gamma Tolerance Level |
50 kGy |
|
Process Connection |
1/4-inch hose barb |
|
Sensor Connector |
M12-8 |
|
Temperature Sensor |
Pt 1000 |
Wetted Materials
| Main Sensor Body | Polysulfone (PSU) |
| Electrodes | Gold plated |
Regulatory Compliance
| USP Class VI | Yes, all wetted parts |
| REACH Compliant | Yes |
| RoHS Compliant | Yes |
| BSE/TSE/ADI Free | Yes |
