Broadley-James offer a wide range of cable assemblies to connect FermProbe pH electrodes with all of today’s pH transmitters and benchtop controllers. The cables and electrodes are color coordinated so that the black HP electrode plug will connect to the standard S8 black cap on the pH electrode.
Users have the option of this thicker, more rugged 5 mm cable or the more flexible, lightweight 3mm low noise coaxial cables. Cables are tagged with replacement part numbers to enhance field serviceability. Cable assemblies are 100% tested for continuity, polarity, and the absence of short circuits.
Specification for pH Cables
| Cable Type | Sensor Connector & Device Connector | Device Terminal |
| HP Plug to BNC Plug, Type M
|
 |
 |
This cable is a Type M 5 mm, low noise, shielded coaxial cable. Thicker and more rugged, the 5 mm cable is often specified for pilot and process installations.
For a more lightweight, flexible cable, choose HP Plug to BNC Plug, Type A.
Stock cable assemblies feature the most commonly requested cable lengths and connector schemes (see Ordering Information tab for part number details). For custom cable assemblies please see the tab for ordering custom cables.
A wide selection of connectors is available upon request.
